Главная Каталог продукции Toolunited 13 306-01 - Twist drill for indexable inserts U45 63320

U45 63320

U45 63320

Komet Group

Артикул: 1497720

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

A1B Cutting edge angle major Pos. B

90 Degree

A2A Clearance angle major Pos. A

8 Degree

A2B Clearance angle major Pos. B

8 Degree

BLDA Tool style code Position A

2

BLDB Tool style code Position B

2

BLDEV Balancing device

0

CCONMS Connection count machine side

1

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DC Cutting diameter minimum

33.2 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

DIN

ABS06300115

FamilyProducts

KUB Pentron 5xD dia. 33.2

FDC Flute design code

3 - Equal helix

GEP Guide element property

0 - Without guide elements

HAND Cutting direction

R - Right

ID Technical product number

1497720

Interface codes

J6 /

ISYC Subclass

306-01 - Twist drill for indexable inserts

LCF Length chip flute

205 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ABS KOMET ABS connection

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0630

LOC-03 DCONMS Diameter

63 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ABS06300115

LPR Protruding length

205 mm

LU Usable length

165 mm

MTP Clamping type code 1st step

S - Screwed on across the bore, with counter bore

Name Identifying order number

U45 63320

NUMBER INSERTS INSIDE Number of inserts inside

1

NUMBER INSERTS OUTSIDE Number of inserts outside

1

OAL Overall length

243 mm

SIG Point angle 1st step

180 Degree

STDNO Standard

ISO 9766 DIN6595

Working process

BVB - Drilling

WT Weight of item

1.28 kg

Наличие погрешности (ADJBY) / Adjustment property (ADJBY)

1 - Radial adjustment possible
