Главная Каталог продукции СЗЦПК инструмент 13 306-01 - Twist drill for indexable inserts DFSP280R5WD32M

DFSP280R5WD32M

DFSP280R5WD32M

DFSP280R5WD32M

Kennametal
Артикул: 5689502
В наличии
В корзину
Описание
Характеристики
BLDA Tool style code Position A
7
BLDB Tool style code Position B
2
CCONMS Connection count machine side
1
CEDC Cutting edge count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter minimum
28 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/28/2017
DIN
ZYL03201315
FamilyProducts
Drill Fix DFSP Bodies WD Shank, 5xD, Metric
HAND Cutting direction
R - Right
ID Technical product number
5689502
Interface codes
J6 /
ISYC Subclass
306-01 - Twist drill for indexable inserts
LOC-03 CCFMS Connection code form
13
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03201315
LS Shank length
58 mm
LU Usable length
140 mm
MTP Clamping type code 1st step
S - Screwed on across the bore, with counter bore
Name Identifying order number
DFSP280R5WD32M
NUMBER INSERTS INSIDE Number of inserts inside
1
NUMBER INSERTS OUTSIDE Number of inserts outside
1
OAL Overall length
175 mm
PL Point length
0.8 mm
Working process
BVB - Drilling
