12165622000
12165622000
Артикул:
12165622000
В наличии
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
BI Block index
1
CCONMS Connection count machine side
1
CEDC Cutting edge count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
WI - Widia
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter minimum
20 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
255.4 €
DF Flange diameter
43 mm
DIN
ZYL02501015
FamilyProducts
Top Cut Plus 2 x D
HAND Cutting direction
R - Right
ID Technical product number
12165622000
Interface codes
J6 /
ISYC Subclass
306-01 - Twist drill for indexable inserts
LOC-01 BI Block index
1
LOC-01 MIID Master insert identification
XOMT070304
LOC-01 MTP Clamping type code 1st step
S Screwed on across the bore, with counter bore
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
XO0703043N
LOC-03 CCFMS Form
10
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
1 Metric with coolant
LOC-03 CZCMS Size code
0250
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02501015
LPR Protruding length
56 mm
LU Usable length
40 mm
MIID Master insert identification
XOMT070304
MTP Clamping type code 1st step
S
Name Identifying order number
12165622000
OAL Overall length
112 mm
Working process
BVB - Drilling
