Главная Каталог продукции Toolunited 13 305-03 - Bridge tool EB731

EB731

Артикул: 8217297

В наличии

В корзину

Описание

Характеристики

BMC Body material code

L - Light alloy

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

W - Walter

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

Delivery state valid from

12/1/2024

DIN

SPK10160293

FamilyProducts

Precision XT and Boring XT - Bridge EB700

HAND Cutting direction

R - Right

ID Technical product number

8217297

Interface codes

J6 / J61

Interface codes CSW1

J41 / J441

ISO

SPK02A1016$$$$

ISYC Subclass

305-03 - Bridge tool

LF Functional length

62 mm

LOC-01 CCFWS Form

LOC-01 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Type

CBC Coromant Bridge Connection SANDVIK

LOC-01 CCUWS Unit base

9 non-dimensional size with coolant

LOC-01 CZCWS Size code

0240

LOC-01-Connection-codes

J41 / J441 - Interface code position A (cutting edge)

LOC-03 CCFMS Form

LOC-03 CCSMS Style

3 Hole pattern (through bore) machine side or hole pattern (threaded hole) machine side or

LOC-03 CCTMS Type

SPK Spindle nose mounting

LOC-03 CCUMS Unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Size code

1016

LOC-03 DCONMS Diameter

40 mm

LOC-03 ISO

SPK02A1016$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SPK10160293

Name Identifying order number

EB731

OAW Overall width

278 mm

Working process

BAB - Open by boring

WT Weight of item

5.33 kg
