Главная Каталог продукции Toolunited 13 303-00 - End mill unspecified S06.2020.02.14 F GT42

S06.2020.02.14 F GT42

S06.2020.02.14 F GT42

S06.2020.02.14 F GT42

Simtek
Артикул: S0620200214FGT42
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
1.236 mm
APMX Depth of cut maximum 2
2.673 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
TiAlN
COMPC Company code
SIM - Simtek
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
12.8 mm
DC Cutting diameter 3
12.8 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
13.7 mm
Delivery state valid from
1/4/2024
DIN
SIM-SD08.0
FamilyProducts
Chamfering
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
GT42
GRDPRIO Standard designation of the grade main application
HC
HAND Cutting direction
R - Right
ID Technical product number
S0620200214FGT42
Interface codes
J6 / J61
ISO
SIM$SD08.0
ISYC Subclass
303-00 - End mill unspecified
LF Functional length
2.3 mm
LOC-03 CCSMS Connection code style
7 Serrated connection
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 ISO
SIM$SD08.0
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SIM-SD08.0
LPR Protruding length
4.7 mm
Materials
S
Name Identifying order number
S06.2020.02.14 F GT42
OAL Overall length
5.6 mm
PRFA Profile included angle
40 Degree
PRFA Profile included angle 2
40 Degree
RPMX Rotational speed maximum
2550 1/min
Working process
FPR - Profile milling
WT Weight of item
0.004 kg
ZEFF Face effective cutting edge count
6
ZEFP Peripheral effective cutting edge count
6
