Главная Каталог продукции Toolunited 13 301-03 - Thread forming tap with offset shank 1110101130

1110101130

1110101130 1110101130

1110101130

Yamawa
Артикул: 1110101130
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL01402105
DRVS Drive size
11 mm
FamilyProducts
MHRZ G10 M18X1.5 P coated tap
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-Co
HAND Cutting direction
R - Right
ID Identifying order number
1110101130
Interface codes
J6 /
ISYC Subclass
301-03 - Thread forming tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0140
LOC-03 DCONMS Diameter
14 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01402105
LS Shank length
64 mm
Materials
P,M,N,H
NOF Flute count
8
OAL Overall length
125 mm
OVERHANG LENGTH Overhang length
67.4 mm
PLCD Gate diameter
17.1 mm
PLG Plug style
D - Kappa r 8°
STDNO Standard
JIS
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
6 mm
TCTR Thread tolerance class
G10
TD Thread diameter
18 mm
THFT Thread form type
MF
THL Thread cutting part length
20 mm
THOD Thread designation
MF18x1.5-G10
TP Thread pitch
1.5 mm
TTPID Tap type identifier
4 - Forming tap
Working process
GFD - Thread forming, through hole
WT Weight of item
0.156 kg
