DCMT11T308N-LB AC8115P
DCMT11T308N-LB AC8115P
Артикул:
DCMT11T308N-LB AC8115P
В наличии
Характеристики
AN Clearance angle major
7 Degree
CB Chip breaker face count
1 - With chip breaker one-side
CBMD Chip breaker manufacturers designation
LB
CECC Cutting edge condition code
E - Rounded
COATN Coating
Absotech
COMPC Company code
SU - Sumitomo
D1 Fixing hole diameter
4.4 mm
Delivery state valid from
12/1/2024
DIN
DC11T3083N
EPSR Insert included angle
55 Degree
FamilyProducts
Indexable Insert
GRDMFG Grade manufacturers designation
AC8115P
IC Inscribed circle diameter
9.525 mm
IFS Insert mounting style code
3 - Counter bore for screws with taper angle from 40° to 60°
IH Insert hand
N - Neutral
Interface codes
J6 / J441
ISISO ISO property
1
ISYC Subclass
201-03 - Rhombic insert
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
DC11T3083N
MIID Master insert identification
DCMT11T308N
Name Identifying order number
DCMT11T308N-LB AC8115P
RE Corner radius
0.8 mm
S Insert thickness
3.97 mm
S1 Insert thickness total
3.97 mm
STDNO Standard
DIN ISO 1832
TCINS Tolerance class insert
M
Working process
No working processes available
