CNMG160616N-GE AC8115P
CNMG160616N-GE AC8115P
Артикул:
CNMG160616N-GE AC8115P
В наличии
Характеристики
AN Clearance angle major
0 Degree
CB Chip breaker face count
2 - With chip breaker on both sides
CBMD Chip breaker manufacturers designation
GE
CECC Cutting edge condition code
E - Rounded
COATN Coating
Absotech
COMPC Company code
SU - Sumitomo
D1 Fixing hole diameter
6.35 mm
Delivery state valid from
12/1/2024
DIN
CN1606162N
EPSR Insert included angle
80 Degree
FamilyProducts
Indexable Insert
GRDMFG Grade manufacturers designation
AC8115P
IC Inscribed circle diameter
15.875 mm
IFS Insert mounting style code
2 - With cylindrical bore
IH Insert hand
N - Neutral
Interface codes
J6 / J441
ISISO ISO property
1
ISYC Subclass
201-03 - Rhombic insert
L Cutting edge length
16.1 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
CN1606162N
MIID Master insert identification
CNMG160616N
Name Identifying order number
CNMG160616N-GE AC8115P
RE Corner radius
1.6 mm
S Insert thickness
6.35 mm
S1 Insert thickness total
6.35 mm
STDNO Standard
DIN ISO 1832
TCINS Tolerance class insert
M
Working process
No working processes available
