Главная Каталог продукции Toolunited 13 201-10 - Round insert RCMX 160600 RA TT8135B

RCMX 160600 RA TT8135B

Артикул: 6213005

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

0 - Without chip breaker

CBMD Chip breaker manufacturers designation

COATN Coating

TiCN+Al2O3+TiN

COMPC Company code

IL - Ingersoll

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.2 mm

Delivery state valid from

7/1/2024

DIN

IL-WSP-3015

FamilyProducts

insert, Positive round Insert - 7° clearance for medium roughing / steel

GRDMFG Grade manufacturers designation

TT8135B

GRDPRIO Standard designation of the grade main application

P25-P40

IC Inscribed circle diameter

16 mm

ID Technical product number

6213005

IFS Insert mounting style code

7 - Prismatic clamping, concave

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISYC Subclass

201-10 - Round insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

IL-WSP-3015

Materials

MIID Master insert identification

RCMX160600 TT8135B

Name Identifying order number

RCMX 160600 RA TT8135B

S Insert thickness

6.35 mm

S1 Insert thickness total

6.35 mm

STDDES Standard designation

RCMX160600

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available
