Главная Каталог продукции Toolunited 13 201-10 - Round insert RCMX 100300 TT8115B

RCMX 100300 TT8115B

Артикул: 6212359

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

0 - Without chip breaker

COATN Coating

TiCN+Al2O3+TiN

COMPC Company code

IL - Ingersoll

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

3.6 mm

Delivery state valid from

7/1/2024

DIN

IL-WSP-1211

FamilyProducts

insert, Positive 7° clearance round inserts for roughing

GRDMFG Grade manufacturers designation

TT8115B

GRDPRIO Standard designation of the grade main application

P05-P20

IC Inscribed circle diameter

10 mm

ID Technical product number

6212359

IFS Insert mounting style code

7 - Prismatic clamping, concave

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISYC Subclass

201-10 - Round insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

IL-WSP-1211

Materials

MIID Master insert identification

RCMX100300 TT8115B

Name Identifying order number

RCMX 100300 TT8115B

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

RCMX100300

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available
