Главная Каталог продукции Toolunited 13 401-00 - Adaptive item converter, extender, reducer unspecified XS3110061T2RT1

XS3110061T2RT1

Артикул: 6248022

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state valid from

2/27/2024

DIN

ZYL01200115

FamilyProducts

Holder reaming head S - 3D / 5D (RT1)

HAND Cutting direction

R - Right

ID Technical product number

6248022

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

IL-K-XT3

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01200115

LPR Protruding length

60.5 mm

Name Identifying order number

XS3110061T2RT1

OAL Overall length

114.5 mm

WT Weight of item

0.071 kg
