Главная Каталог продукции Toolunited 13 303-09 - Thread end mill GFR35105.0080

GFR35105.0080

Артикул: GFR35105.0080

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COATN Coating

TiN-T49

COMPC Company code

E - Emuge

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

6.25 mm

Delivery state valid from

2/1/2024

DIN

ZYL02501035

FamilyProducts

solid carbide thread milling cutters

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

VHM-TiN-T4

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

44.45 mm

LH Head length

16.841 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

3 Inch with coolant

LOC-03 CZCMS Connection size code

0250

LOC-03 DCONMS Diameter

6.35 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02501035

LPR Protruding length

28.6 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GFR35105.0080

OAL Overall length

63.5 mm

TD Thread diameter

8 mm

THFT Thread form type

TP Thread pitch

1.25 mm

Working process

FSC - Thread milling

ZEFP Peripheral effective cutting edge count
