Главная Каталог продукции Toolunited 13 303-09 - Thread end mill GF332406.5013

GF332406.5013

Артикул: GF332406.5013

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COATN Coating

TiCN

COMPC Company code

E - Emuge

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

10.35 mm

Delivery state valid from

2/1/2024

DIN

ZYL01401315

FamilyProducts

solid carbide thread milling cutters with countersinking step

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

VHM-TiCN

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

90 mm

LH Head length

26.426 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0140

LOC-03 DCONMS Diameter

14 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01401315

LPR Protruding length

45 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF332406.5013

OAL Overall length

90 mm

TDIN Thread diameter nominal inch

12.7 in

THFT Thread form type

UNC

TP Thread pitch

1.954 mm

TPI Threads per inch

13 1/in

Working process

FSC - Thread milling

WT Weight of item

0.157 kg

ZEFP Peripheral effective cutting edge count
