Главная Каталог продукции Toolunited 13 303-09 - Thread end mill GF332401.5009

GF332401.5009

Артикул: GF332401.5009

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

E - Emuge

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

4.7 mm

Delivery state valid from

2/1/2024

DIN

ZYL00801315

FamilyProducts

solid carbide thread milling cutters with countersinking step

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

VHM

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

62 mm

LH Head length

13.359 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00801315

LPR Protruding length

26 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF332401.5009

OAL Overall length

62 mm

TDIN Thread diameter nominal inch

6.35 in

THFT Thread form type

UNC

TP Thread pitch

1.27 mm

TPI Threads per inch

20 1/in

Working process

FSC - Thread milling

WT Weight of item

0.036 kg

ZEFP Peripheral effective cutting edge count
