Главная Каталог продукции Toolunited 13 303-09 - Thread end mill GF26A729.5001

GF26A729.5001

Артикул: GF26A729.5001

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

TiAlN-T46

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

1.7 mm

Delivery state valid from

2/1/2024

DIN

ZYL00300105

FamilyProducts

solid carbide circular thread mills

FHH Flute helix hand

L - Hand of helix left

GRDMFG Grade manufacturers designation

VHM-TiAlN-

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

L - Left

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LH Head length

5 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0030

LOC-03 DCONMS Diameter

3 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00300105

LPR Protruding length

11 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF26A729.5001

OAL Overall length

39 mm

TDIN Thread diameter nominal inch

2.184 in

THFT Thread form type

UNC

TP Thread pitch

0.454 mm

TPI Threads per inch

56 1/in

Working process

FSC - Thread milling

WT Weight of item

0.003 kg

ZEFP Peripheral effective cutting edge count
