GF175306.5783

Артикул: GF175306.5783

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COATN Coating / Покрытие

TiCN

COMPC Company code

E - Emuge

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

7.65 mm

Delivery state valid from

2/1/2024

DIN

ZYL00801015

FamilyProducts

solid carbide thread milling cutters for tapered threads

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

VHM-TiCN

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

42 mm

LH Head length

13.599 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00801015

LPR Protruding length

24 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF175306.5783

OAL Overall length

60 mm

TDIN Thread diameter nominal inch

10.126 in

THFT Thread form type

NPTF

TP Thread pitch

0.941 mm

TPI Threads per inch

27 1/in

Working process

FSC - Thread milling

WT Weight of item

0.034 kg

ZEFP Peripheral effective cutting edge count
