GF173111.5766

Артикул: GF173111.5766

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

E - Emuge

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

11.15 mm

Delivery state valid from

2/1/2024

DIN

ZYL01201015

FamilyProducts

solid carbide thread milling cutters for tapered threads

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

VHM

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

52.5 mm

LH Head length

14.784 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01201015

LPR Protruding length

30 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF173111.5766

OAL Overall length

75 mm

TDIN Thread diameter nominal inch

16.978 in

THFT Thread form type

NPT

TP Thread pitch

1.411 mm

TPI Threads per inch

18 1/in

Working process

FSC - Thread milling

WT Weight of item

0.105 kg

ZEFP Peripheral effective cutting edge count
