Главная Каталог продукции Toolunited 13 311-01 - Solid cylindrical reamer 412 19.500

412 19.500

412 19.500 412 19.500 412 19.500 412 19.500

412 19.500

Gühring
Артикул: 9004120195000
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
APMX Depth of cut maximum
100 mm
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
OHNE
COMPC Company code
GG - Gühring
CPDF Cutting pitch differential
1 - Unequal (e.g. 58-60-62 degree)
CRCLDIN Tool application class
N
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
19.5 mm
DCONMSLD Shank diameter lower limit
-0.092 mm
DCONMSUD Shank diameter upper limit
-0.04 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL01952105
FamilyProducts
HSS HAND-REIBAHLE 19,500 DIN206-A RN ZYL
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
HSS
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
ID Technical product number
9004120195000
Interface codes
J6 /
ISYC Subclass
311-01 - Solid cylindrical reamer
LF Functional length
200.6 mm
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0195
LOC-03 DCONMS Diameter
19.5 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01952105
LPR Protruding length
182 mm
LS Shank length
83 mm
LU Usable length
118 mm
Name Identifying order number
412 19.500
NOF Flute count
8
OAL Overall length
201 mm
PLANG Plug angle
45
PLGL Plug length
0.4 mm
RESYC Reaming tool style code
0 - For through-holes and blind holes
STDLET Standard letter to the standard number
A
STDNO Standard
DIN206
TCDH ISO tolerance class for drilling result
H7
Working process
REI - Cylindrical reaming
WT Weight of item
0.402 kg
