Главная Каталог продукции Toolunited 13 401-01 - Converter, rotationally symmetric AB044-S50-W08-063

AB044-S50-W08-063

AB044-S50-W08-063 AB044-S50-W08-063 AB044-S50-W08-063 AB044-S50-W08-063

AB044-S50-W08-063

Walter
Артикул: 8651616
В наличии
В корзину
Описание
Характеристики
BD Body diameter
15.3 mm
BD Body diameter 2
28 mm
CCFWS Form
10
CCSWS Style
5
CCTWS Type
ZYL
CCUWS Unit base
1
CNSC Coolant entry style code
7 - Coolant entry, decentral and axially concentric
COMPC Company code
W - Walter
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Size code
0080
DCONWS Diameter
8 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2024
DF Flange diameter
97.5 mm
DIN
SKG05001795
FamilyProducts
DIN 69871 AD/B Weldon adaptor AB044-S
ID Technical product number
8651616
Interface codes
J6 / J61
ISO
SKG17C0500$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
KAP Kappa
0 Degree
LB Body length 1
11 mm
LB Length 2
43.95 mm
LF Functional length
63 mm
LOC-01 CCFWS Form
10
LOC-01 CCSWS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Type
ZYL cylindrical shank
LOC-01 CCUWS Unit base
1 Metric with coolant
LOC-01 CZCWS Size code
0080
LOC-01 DCONWS Diameter
8 mm
LOC-01 ISO
ZYL10F8000****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL00801015
LOC-02 ISO
ZYL10R3149****
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
ZYL00801815
LOC-03 CCFMS Form
17
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
SKG steep taper shank
LOC-03 CCUMS Unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Size code
0500
LOC-03 DCONMS Diameter
8 mm
LOC-03 ISO
SKG17C0500$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05001795
LPR Protruding length
63 mm
LS Shank length
101.75 mm
Name Identifying order number
AB044-S50-W08-063
OAL Overall length
164.6 mm
Rotation Rotation indicator
1 - rotating tool
RPMX Rotational speed maximum
12000 1/min
STDLET Standard letter to the standard number
AD
STDNO Standard
ISO7388-1
WT Weight of item
2.705 kg
