Главная Каталог продукции Toolunited 13 303-02 - Centre cutting end mill 5743 4.000

5743 4.000

Артикул: 5743 4.000

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

8 mm

BMC Body material code

H - Solid carbide

CHW Corner chamfer width

0.03 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

4 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/18/2024

DIN

ZYL00600105

F71 Number of corner designs

FamilyProducts

VHM SCHAFTFRAESER

FHA Flute helix angle

45 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

12.5 mm

GAMF Rake angle radial

45 Degree

GAMP Rake angle axial

25 Degree

GRD2ND Standard designation of the grade 2nd application

GRDMFG Grade manufacturers designation

GRDPRIO Standard designation of the grade main application

HF-K

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

KCH Corner chamfer angle

45 Degree

LF Functional length

57 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

LPR Protruding length

21 mm

LS Shank length

36 mm

MILTTY Mill tool type ISO

H - Slotting end mill (one or more indexable insert pro cutting edge) 90°

Name Identifying order number

5743 4.000

OAL Overall length

57 mm

STDLET Standard letter to the standard number

STDNO Standard

DIN 6527L

Working process

FNB - Slotting

WT Weight of item

0.018 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
