Главная Каталог продукции Toolunited 13 303-02 - Centre cutting end mill 5493 20.000

5493 20.000

Артикул: 5493 20.000

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

12 mm

BMC Body material code

B - Steel body with brazed carbide inserts

CNSC Coolant entry style code

4 - With Coolant entry, axial on hole circle

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

DC Cutting diameter

20 mm

DCONMSLD Shank diameter lower limit

-0.013 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/18/2024

DIN

ZYL02000135

F71 Number of corner designs

FamilyProducts

PKD FRAESER

FHA Flute helix angle

4 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

4 Degree

GRD2ND Standard designation of the grade 2nd application

PKD

GRDMFG Grade manufacturers designation

PKD

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

3 Inch with coolant

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02000135

LPR Protruding length

100 mm

LS Shank length

100 mm

MILTTY Mill tool type ISO

H - Slotting end mill (one or more indexable insert pro cutting edge) 90°

Name Identifying order number

5493 20.000

OAL Overall length

150 mm

RE Corner radius

0.1 mm

Working process

FNB - Slotting

WT Weight of item

0.5 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
