19951 3.000
19951 3.000
Артикул:
9199510030000
В наличии
Характеристики
APMX Depth of cut maximum
16 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
3 mm
DCONMSLD Shank diameter lower limit
-0.008 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL00400105
F71 Number of corner designs
1
FamilyProducts
VHM ALCRN-POWERMILL FRA WN RN 35/38° ZYL
FHA Flute helix angle
35 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
13.2 mm
GAMF Rake angle radial
35 Degree
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HF
HAND Cutting direction
R - Right
ID Technical product number
9199510030000
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
LF Functional length
60 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0040
LOC-03 DCONMS Diameter
4 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00400105
LPR Protruding length
23 mm
LS Shank length
37 mm
MILTTY Mill tool type ISO
H - Slotting end mill (one or more indexable insert pro cutting edge) 90°
Name Identifying order number
19951 3.000
OAL Overall length
60 mm
Working process
FEC - Square shoulder milling
WT Weight of item
0.01 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
ZNC Cutting edge centre count
2
