4113 21.030
4113 21.030
Артикул:
9041130210300
В наличии
Характеристики
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
SIGNUM-BESCHICHTET
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
21.03 mm
Delivery state valid from
1/18/2024
DIN
GG-HTW0210
FamilyProducts
WECHSELPLATTE
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HC-K/P
GRDSYC Grind style code
A
HAND Cutting direction
R - Right
ID Technical product number
9041130210300
Interface codes
J6 /
ISYC Subclass
203-03 - Replaceable insert flatted with chip flute
LF Functional length
8.8 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
GG-HTW0210
LPR Protruding length
13.9 mm
Name Identifying order number
4113 21.030
NOF Flute count
2
OAL Overall length
17 mm
OALN
8.8 mm
PL Point length
5.1 mm
S1 Insert thickness total
9 mm
SIG Point angle 1st step
140 Degree
Working process
BVB - Drilling
WT Weight of item
0.031 kg
