Главная Каталог продукции Toolunited 13 302-04 - Counterbore 521 11.000

521 11.000

Артикул: 9005210110000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

OHNE

COMPC Company code

GG - Gühring

CRCLDIN Chip removal class

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

11 mm

DCONMSLD Shank diameter lower limit

-0.036 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/18/2024

DIN

ZYL00800105

FamilyProducts

505120 SIMETA HSS FLACHSENKER FF DIN373

FHH Flute helix hand

R - Hand of helix right

GEP Guide element property

0 - Without guide elements

GPD Guide pilot diameter

6.4 mm

GPL Guide pilot length

6.3 mm

GPP Guide pilot

1 - With fixed pilot

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

HAND Cutting direction

R - Right

ID Technical product number

9005210110000

Interface codes

J6 /

ISYC Subclass

302-04 - Counterbore

LCF Length chip flute

35 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800105

LPR Protruding length

45 mm

LS Shank length

35.5 mm

LU Usable length

44.5 mm

Name Identifying order number

521 11.000

NOF Flute count

OAL Overall length

80 mm

PHD Premachined hole diameter

6.4 mm

SIG Point angle 1st step

180 Degree

STDNO Standard

DIN373

Working process

SPL - Spot facing

WT Weight of item

0.028 kg
