156020 20X13
156020 20X13
Артикул:
156020 20X13
В наличии
Характеристики
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
20 mm
DCINTF Interference cutting diameter
10 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/11/2017
DIN
ZYL01250105
FamilyProducts
GARANT DIN counterbore for through holes
FHA Flute helix angle
27 Degree
FHH Flute helix hand
R - Hand of helix right
GPD Guide pilot diameter
13 mm
GPL Guide pilot length
10 mm
GRDMFG Grade manufacturers designation
HSS
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
302-04 - Counterbore
LCF Length chip flute
46 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0125
LOC-03 DCONMS Diameter
12.5 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01250105
LPR Protruding length
60 mm
LU Usable length
22 mm
Name Identifying order number
156020 20X13
NOF Flute count
3
OAL Overall length
100 mm
SIG Point angle 1st step
180 Degree
Working process
BVB - Drilling
WT Weight of item
0.1 kg
