M9105-0390AK

M9105-0390AK M9105-0390AK

M9105-0390AK

Mapal
Артикул: 30260867
В наличии
В корзину
Описание
Характеристики
BMC Body material code
H - Solid carbide
CCONMS Connection count machine side
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COATN Coating / Покрытие
Mx2
COMPC Company code
MP - Mapal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter minimum
3.9 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
9/15/2009
DIN
ZYL00600105
FamilyProducts
5xD MEGA-Speed solid carbide drill w/ coolant
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
M9105
GRDSYC Grind style code
A
HAND Cutting direction
R - Right
ID Technical product number
30260867
Interface codes
J6 /
ISYC Subclass
302-01 - Twist Drill
LCF Length chip flute
36 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0060
LOC-03 DCONMS Diameter
6 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00600105
LS Shank length
36 mm
LU Usable length
29 mm
Materials
P,M,K,H
Name Identifying order number
M9105-0390AK
NOF Flute count
2
OAL Overall length
74 mm
SIG Point angle 1st step
135 Degree
Working process
BVB - Drilling
