Главная Каталог продукции Toolunited 13 302-01 - Twist Drill A1148-43/64IN

A1148-43/64IN

A1148-43/64IN A1148-43/64IN A1148-43/64IN

A1148-43/64IN

Walter
Артикул: 5154973
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
W - Walter
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
17.066 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
ZYL06710125
FamilyProducts
HSS-E twist drills, extra short A1148
FHA Flute helix angle
40 Degree
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
UNBESCHICH
HAND Cutting direction
R - Right
ID Technical product number
5154973
Interface codes
J6 / J61
ISO
ZYL01R6718f$11
ISYC Subclass
302-01 - Twist Drill
LCF Length chip flute
62 mm
LDRED Neck length
44 mm
LF Functional length
119.02 mm
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0671
LOC-03 DCONMS Diameter
17.066 mm
LOC-03 TCDCONCDMS Tolerance class coded
f$11
LOC-03 ISO
ZYL01R6718f$11
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL06710125
LPR Protruding length
70.529 mm
LS Shank length
52.47 mm
LU Usable length
44 mm
Materials
P,M,K,N,S,O
Name Identifying order number
A1148-43/64IN
NOF Flute count
2
OAL Overall length
123 mm
PL Point length
3.979 mm
RPMX Rotational speed maximum
100000 1/min
SIG Point angle 1st step
130 Degree
STDNO Standard
DIN 1897
TCDCONMS ISO-tolerance class shank diameter
f11
Working process
BVB - Drilling
WT Weight of item
0.174 kg
