Главная Каталог продукции Toolunited 13 302-01 - Twist Drill 701 0.680

701 0.680

Артикул: 701 0.680

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

0.68 mm

DCONMSLD Shank diameter lower limit

-0.01 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/18/2024

DIN

ZYL00100105

FamilyProducts

KLEINSTBOHRER

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRD2ND Standard designation of the grade 2nd application

K10/K20

GRDMFG Grade manufacturers designation

K10/K20

GRDPRIO Standard designation of the grade main application

HF-K

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

4.8 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0010

LOC-03 DCONMS Diameter

1 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00100105

LPR Protruding length

6.1 mm

LS Shank length

18.8 mm

LU Usable length

3.9 mm

Name Identifying order number

701 0.680

NOF Flute count

OAL Overall length

25 mm

SIG Point angle 1st step

130 Degree

Working process

BVB - Drilling

WT Weight of item

0.001 kg
