672 18.500
672 18.500
Артикул:
672 18.500
В наличии
Характеристики
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
TIN
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
18.5 mm
DCONMSLD Shank diameter lower limit
-0.15 mm
DCONMSUD Shank diameter upper limit
-0.02 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL01850105
FamilyProducts
S-SPIRALBOHRER
FHA Flute helix angle
30 Degree
FHP Flute helix pitch
95 mm
GRDSYC Grind style code
A
HAND Cutting direction
L - Left
Interface codes
J6 /
ISYC Subclass
302-01 - Twist Drill
LCF Length chip flute
64 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0185
LOC-03 DCONMS Diameter
18.5 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
f$11
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01850105
LPR Protruding length
69 mm
LS Shank length
63 mm
LU Usable length
40 mm
Name Identifying order number
672 18.500
NOF Flute count
2
OAL Overall length
127 mm
SIG Point angle 1st step
118 Degree
STDNO Standard
DIN 1897
TCDCONMS ISO-tolerance class shank diameter
f11
Working process
BVB - Drilling
WT Weight of item
0.204 kg
