Главная Каталог продукции Toolunited 13 302-01 - Twist Drill 1703 4.400

1703 4.400

Артикул: 1703 4.400

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

TIALN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

4.4 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/18/2024

DIN

ZYL00440105

FamilyProducts

A-RATIOBOHRER

FHA Flute helix angle

15 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

53 mm

GRD2ND Standard designation of the grade 2nd application

K05

GRDMFG Grade manufacturers designation

K05

GRDPRIO Standard designation of the grade main application

HC-K/P

GRDSYC Grind style code

GG-RK

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

24 mm

LF Functional length

57.1 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0044

LOC-03 DCONMS Diameter

4.4 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00440105

LPR Protruding length

29 mm

LS Shank length

34 mm

LU Usable length

12 mm

Name Identifying order number

1703 4.400

NOF Flute count

OAL Overall length

58 mm

PL Point length

0.9 mm

SIG Point angle 1st step

140 Degree

STDNO Standard

DIN 6539

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling

WT Weight of item

0.011 kg
