Главная Каталог продукции Toolunited 13 302-01 - Twist Drill 1189 15.500

1189 15.500

Артикул: 1189 15.500

В наличии

В корзину

Описание

Характеристики

BMC Body material code

B - Steel body with brazed carbide inserts

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

15.5 mm

DCONMSLD Shank diameter lower limit

-0.126 mm

DCONMSUD Shank diameter upper limit

-0.016 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/18/2024

DIN

ZYL01552005

FamilyProducts

HM-BEST. BOHRER

FHA Flute helix angle

20 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

132 mm

GRDMFG Grade manufacturers designation

K10/K20

GRDPRIO Standard designation of the grade main application

GRDSYC Grind style code

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

120 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0155

LOC-03 DCONMS Diameter

15.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01552005

LPR Protruding length

125 mm

LS Shank length

20 mm

LU Usable length

92 mm

Name Identifying order number

1189 15.500

NOF Flute count

OAL Overall length

140 mm

PL Point length

4.7 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

DIN 8037

Working process

BVB - Drilling

WT Weight of item

0.147 kg
