Главная Каталог продукции Toolunited 13 302-01 - Twist Drill 114050 10,6

114050 10,6

Артикул: 114050 10,6

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

HOG - Hoffmann Group

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

10.6 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/11/2017

DIN

ZYL01060105

FamilyProducts

GARANT Jobber drill HSS N

FHA Flute helix angle

29 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

HSS

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

87 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0106

LOC-03 DCONMS Diameter

10.6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01060105

LPR Protruding length

103 mm

LU Usable length

60.7 mm

Name Identifying order number

114050 10,6

NOF Flute count

OAL Overall length

133 mm

PL Point length

3.063 mm

SIG Point angle 1st step

118 Degree

Working process

BVB - Drilling

WT Weight of item

0.0635 kg
