1028 11.100
1028 11.100
Артикул:
1028 11.100
В наличии
Характеристики
BMC Body material code
H - Solid carbide
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
11.1 mm
DCONMSLD Shank diameter lower limit
-0.011 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL01110105
FamilyProducts
RATIOBOHRER
FHA Flute helix angle
28 Degree
FHH Flute helix hand
L - Hand of helix left
FHP Flute helix pitch
71 mm
GRDPRIO Standard designation of the grade main application
HF-K
GRDSYC Grind style code
GG-KG
HAND Cutting direction
L - Left
Interface codes
J6 /
ISYC Subclass
302-01 - Twist Drill
LCF Length chip flute
60 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0111
LOC-03 DCONMS Diameter
11.1 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01110105
LPR Protruding length
65 mm
LS Shank length
35 mm
LU Usable length
45 mm
Name Identifying order number
1028 11.100
NOF Flute count
3
OAL Overall length
95 mm
PL Point length
1.5 mm
SIG Point angle 1st step
150 Degree
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
BVB - Drilling
WT Weight of item
0.086 kg
