Главная Каталог продукции СЗЦПК инструмент 13 301-02 - Thread cutting tap with reinforced shank BU99C410.5639

BU99C410.5639

BU99C410.5639

BU99C410.5639

Emuge
Артикул: BU99C410.5639
В наличии
В корзину
Описание
Характеристики
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COATN Coating / Покрытие
GLT-1
COMPC Company code
E - Emuge
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCP Data chip provision
0 - Without data chip
Delivery state valid from
2/1/2024
DIN
ZYL03182135
DRVS Drive size
6.05 mm
FamilyProducts
machine tap
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
32 mm
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
3 Inch with coolant
LOC-03 CZCMS Connection size code
0318
LOC-03 DCONMS Diameter
8.077 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03182135
Name Identifying order number
BU99C410.5639
OAL Overall length
90 mm
PLG Plug style
E - Kappa r 23°
TCTR Thread tolerance class
3B
TD Thread diameter
7.528 mm
TDFR Thread diameter nominal fraction
1/4 in
TDIN Thread diameter nominal inch
0.25 in
THFT Thread form type
EG-UNF
TP Thread pitch
0.907 mm
TPI Threads per inch
28 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.028 kg
