Главная Каталог продукции Toolunited 13 301-02 - Thread cutting tap with reinforced shank 5103101079

5103101079

5103101079 5103101079

5103101079

Yamawa
Артикул: 5103101079
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
10/1/2024
DIN
ZYL00962105
DN Neck diameter
8.5 mm
DRVS Drive size
7.26 mm
FamilyProducts
VUSP 1.5P D6 M10X1.25 coated tap
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
5103101079
Interface codes
J6 / J61
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LCF Length chip flute
38 mm
LDRED Neck length
39 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0096
LOC-03 DCONMS Diameter
9.68 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00962105
LS Shank length
54 mm
LU Usable length
39 mm
Materials
P,M,K,N,H
NOF Flute count
3
OAL Overall length
100 mm
OVERHANG LENGTH Overhang length
51.4 mm
PLCD Gate diameter
8.5 mm
PLG Plug style
E - Kappa r 23°
STDNO Standard
ANSI
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
1.875 mm
TCTR Thread tolerance class
D6
TD Thread diameter
10 mm
THFT Thread form type
MF
THL Thread cutting part length
13 mm
THOD Thread designation
MF10×1,25-D6
TP Thread pitch
1.25 mm
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.051 kg
