Главная Каталог продукции Toolunited 13 301-02 - Thread cutting tap with reinforced shank 5102103048

5102103048

5102103048 5102103048

5102103048

Yamawa
Артикул: 5102103048
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL05422125
DN Neck diameter
4.394 mm
DRVS Drive size
4.191 mm
FamilyProducts
VUPO GH3 12-28UNF coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
5102103048
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
24.994 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0542
LOC-03 DCONMS Diameter
13.7668 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL05422125
LS Shank length
49.606 mm
Materials
P,M,K,N,H
NOF Flute count
2
OAL Overall length
80.01 mm
OVERHANG LENGTH Overhang length
35.56 mm
PLCD Gate diameter
4.445 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
ANSI
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
4.521 mm
TCTR Thread tolerance class
GH3
TDIN Thread diameter nominal inch
0.216 in
TDZ Thread diameter size
12
THFT Thread form type
UNF
THL Thread cutting part length
15.011 mm
THOD Thread designation
UNF12-28-GH3
TP Thread pitch
0.907 mm
TPI Threads per inch
28 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.015 kg
