Главная Каталог продукции Toolunited 13 301-02 - Thread cutting tap with reinforced shank 5102103039

5102103039

5102103039 5102103039

5102103039

Yamawa
Артикул: 5102103039
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL04802125
DN Neck diameter
3.581 mm
DRVS Drive size
3.861 mm
FamilyProducts
VUPO GH3 10-24UNC coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
5102103039
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
24.003 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0480
LOC-03 DCONMS Diameter
12.192 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL04802125
LS Shank length
42.012 mm
Materials
P,M,K,N,H
NOF Flute count
2
OAL Overall length
70.002 mm
OVERHANG LENGTH Overhang length
33.02 mm
PLCD Gate diameter
3.607 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
ANSI
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
5.283 mm
TCTR Thread tolerance class
GH3
TDIN Thread diameter nominal inch
0.19 in
TDZ Thread diameter size
10
THFT Thread form type
UNC
THL Thread cutting part length
13.995 mm
THOD Thread designation
UNC10-24-GH3
TP Thread pitch
1.059 mm
TPI Threads per inch
24 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.011 kg
