Главная Каталог продукции Toolunited 13 301-02 - Thread cutting tap with reinforced shank 5101303058

5101303058

5101303058 5101303058

5101303058

Yamawa
Артикул: 5101303058
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL03672125
DN Neck diameter
4.877 mm
DRVS Drive size
4.851 mm
FamilyProducts
VUSP GH5 1/4-20UNC coated tap
FHA Flute helix angle
50 Degree
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
5101303058
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
29.997 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0367
LOC-03 DCONMS Diameter
9.3218 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03672125
LS Shank length
43.51 mm
Materials
P,M,K,N,H
NOF Flute count
2
OAL Overall length
80.01 mm
OVERHANG LENGTH Overhang length
40.64 mm
PLCD Gate diameter
4.902 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
ANSI
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
3.175 mm
TCTR Thread tolerance class
GH5
TDFR Thread diameter nominal fraction
1/4 in
TDIN Thread diameter nominal inch
0.25 in
THFT Thread form type
UNC
THL Thread cutting part length
10.998 mm
THOD Thread designation
UNC1/4-20-GH5
TPI Threads per inch
20 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.018 kg
