Главная Каталог продукции Toolunited 13 301-02 - Thread cutting tap with reinforced shank 5101103047

5101103047

5101103047 5101103047

5101103047

Yamawa
Артикул: 5101103047
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL03672125
DN Neck diameter
4.242 mm
DRVS Drive size
4.191 mm
FamilyProducts
VUSP GH3 12-24UNC coated tap
FHA Flute helix angle
50 Degree
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
5101103047
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
24.994 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0367
LOC-03 DCONMS Diameter
9.3218 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03672125
LS Shank length
49.606 mm
Materials
P,M,K,N,H
NOF Flute count
2
OAL Overall length
80.01 mm
OVERHANG LENGTH Overhang length
35.56 mm
PLCD Gate diameter
4.267 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
ANSI
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
2.642 mm
TCTR Thread tolerance class
GH3
TDIN Thread diameter nominal inch
0.216 in
TDZ Thread diameter size
12
THFT Thread form type
UNC
THL Thread cutting part length
8.992 mm
THOD Thread designation
UNC12-24-GH3
TPI Threads per inch
24 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.015 kg
