Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank TP2 M3X0.5-6H-GBW-HE

TP2 M3X0.5-6H-GBW-HE

TP2 M3X0.5-6H-GBW-HE TP2 M3X0.5-6H-GBW-HE

TP2 M3X0.5-6H-GBW-HE

Iscar
Артикул: 4445040
В наличии
В корзину
Описание
Характеристики
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
2/1/2012
DIN
ZYL00222105
FamilyProducts
TP2 M3X0.5-6H-GBW-HE
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
HE
HAND Cutting direction
R - Right
ID Technical product number
4445040
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0022
LOC-03 DCONMS Diameter
2.2 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00222105
Name Identifying order number
TP2 M3X0.5-6H-GBW-HE
NOF Flute count
1
OAL Overall length
55 mm
PLCD Gate diameter
2.5 mm
STDNO Standard
DIN376
TD Thread diameter
3 mm
THFT Thread form type
M
THL Thread cutting part length
11 mm
TP Thread pitch
0.5 mm
Working process
BG - Tapping
