Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank SYU22XTEEXJ

SYU22XTEEXJ

SYU22XTEEXJ SYU22XTEEXJ

SYU22XTEEXJ

Yamawa
Артикул: SYU22XTEEXJ
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
Oxidizing
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL02802105
DRVS Drive size
21 mm
FamilyProducts
HVSP P5 1 3/8-8UN
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
ID Identifying order number
SYU22XTEEXJ
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0280
LOC-03 DCONMS Diameter
28 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02802105
LS Shank length
102 mm
Materials
P,M,N,H
NOF Flute count
4
OAL Overall length
200 mm
OVERHANG LENGTH Overhang length
108.2 mm
PLCD Gate diameter
31.337 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
JIS
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
7.938 mm
TCTR Thread tolerance class
P5
TD Thread diameter
34.925 mm
TDFR Thread diameter nominal fraction
1 3/8 in
THFT Thread form type
UN
THL Thread cutting part length
52 mm
TPI Threads per inch
8 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.943 kg
