Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank SJG0120FET

SJG0120FET

SJG0120FET SJG0120FET

SJG0120FET

Yamawa
Артикул: SJG0120FET
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL02302105
DRVS Drive size
17 mm
FamilyProducts
AUSP P4 G(PF)3/4-14 coated tap
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
ID Identifying order number
SJG0120FET
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0230
LOC-03 DCONMS Diameter
23 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02302105
LS Shank length
71 mm
Materials
P,M,N,H
NOF Flute count
4
OAL Overall length
140 mm
OVERHANG LENGTH Overhang length
76.1 mm
PLCD Gate diameter
24.082 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
JIS
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
4.536 mm
TCTR Thread tolerance class
P4
TD Thread diameter
26.441 mm
TDFR Thread diameter nominal fraction
3/4 in
THFT Thread form type
G
THL Thread cutting part length
28 mm
THOD Thread designation
G3/4-14-P4
TPI Threads per inch
14 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.474 kg
