Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 885 27.007

885 27.007

885 27.007 885 27.007 885 27.007 885 27.007

885 27.007

Gühring
Артикул: 885 27.007
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
OHNE
COMPC Company code
GG - Gühring
CRCLMFG Chip removal class mfg
ST
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.052 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL02002105
DRVS Drive size
16 mm
FamilyProducts
HANDGEWINDEBOHRER
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
HSS
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02002105
LS Shank length
47.8 mm
Name Identifying order number
885 27.007
NOF Flute count
4
OAL Overall length
90 mm
PLCD Gate diameter
25.2 mm
PLG Plug style
D - Kappa r 8°
STDNO Standard
DIN 2181
TAPSC Set identifier
V
TCL Tap chamfer length
6 mm
TCTR Thread tolerance class
ISO2/6H
TD Thread diameter
27 mm
THFT Thread form type
M
THL Thread cutting part length
22 mm
THOD Thread designation
M27x1.5-ISO2/6H
TP Thread pitch
1.5 mm
TTPID Tap type identifier
2 - Hand tap
Working process
No working processes available
WT Weight of item
0.208 kg
