Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 5102103181

5102103181

5102103181 5102103181

5102103181

Yamawa
Артикул: 5102103181
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL06972125
DRVS Drive size
13.284 mm
FamilyProducts
VUPO GH6 7/8-9UNC coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
5102103181
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0697
LOC-03 DCONMS Diameter
17.7038 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL06972125
LS Shank length
70.993 mm
Materials
P,M,K,N,H
NOF Flute count
3
OAL Overall length
140.005 mm
OVERHANG LENGTH Overhang length
76.2 mm
PLCD Gate diameter
19.025 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
ANSI
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
14.097 mm
TCTR Thread tolerance class
GH6
TDFR Thread diameter nominal fraction
7/8 in
TDIN Thread diameter nominal inch
0.875 in
THFT Thread form type
UNC
THL Thread cutting part length
32.995 mm
THOD Thread designation
UNC7/8-9-GH6
TP Thread pitch
2.822 mm
TPI Threads per inch
9 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.265 kg
