Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 5102103142

5102103142

5102103142 5102103142

5102103142

Yamawa
Артикул: 5102103142
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL01682125
DRVS Drive size
9.144 mm
FamilyProducts
VUPO GH5 5/8-18UNF coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
5102103142
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0168
LOC-03 DCONMS Diameter
4.2672 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01682125
LS Shank length
56.007 mm
Materials
P,M,K,N,H
NOF Flute count
3
OAL Overall length
110.007 mm
OVERHANG LENGTH Overhang length
58.42 mm
PLCD Gate diameter
14.275 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
ANSI
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
7.036 mm
TCTR Thread tolerance class
GH5
TDFR Thread diameter nominal fraction
5/8 in
TDIN Thread diameter nominal inch
0.625 in
THFT Thread form type
UNF
THL Thread cutting part length
26.01 mm
THOD Thread designation
UNF5/8-18-GH5
TP Thread pitch
1.412 mm
TPI Threads per inch
18 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.102 kg
