3205101167

3205101167

Yamawa
Артикул: 3205101167
В наличии
В корзину
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
Delivery state valid from
6/1/2024
DIN
ZYL01802115
DRVS Drive size
14.5 mm
FamilyProducts
GGST CH 376 ISO2X M24X3 C(2.5P) coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
ID Identifying order number
3205101167
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
1 Metric with coolant
LOC-03 CZCMS Size code
0180
LOC-03 DCONMS Diameter
18 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01802115
LS Shank length
82 mm
Materials
K,N
NOF Flute count
4
OAL Overall length
160 mm
OVERHANG LENGTH Overhang length
86.2 mm
PLCD Gate diameter
20.6 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN376
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
7.5 mm
TCTR Thread tolerance class
ISO2X
TD Thread diameter
24 mm
THFT Thread form type
M
THL Thread cutting part length
37 mm
THOD Thread designation
M24x3-ISO2X
TP Thread pitch
3 mm
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.315 kg
