Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 3113101091

3113101091

3113101091 3113101091

3113101091

Yamawa
Артикул: 3113101091
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
Oxidizing
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
10/1/2024
DIN
ZYL00902105
DRVS Drive size
7 mm
FamilyProducts
HVPO 374 ISO2X M12X1 B(5P)
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
ID Identifying order number
3113101091
Interface codes
J6 / J61
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LCF Length chip flute
25 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0090
LOC-03 DCONMS Diameter
9 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00902105
LS Shank length
51 mm
Materials
P,M,N,H
NOF Flute count
3
OAL Overall length
100 mm
OVERHANG LENGTH Overhang length
54.1 mm
PLCD Gate diameter
11 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
DIN374
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
5 mm
TCTR Thread tolerance class
ISO2X
TD Thread diameter
12 mm
THFT Thread form type
MF
THL Thread cutting part length
21 mm
THOD Thread designation
MF12×1-ISO2X
TP Thread pitch
1 mm
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.057 kg
