Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 3109101051

3109101051

3109101051 3109101051

3109101051

Yamawa
Артикул: 3109101051
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL00352105
DRVS Drive size
2.7 mm
FamilyProducts
MHSL 374 ISO2X M5X0.5 coated tap
FHA Flute helix angle
15 Degree
FHH Flute helix hand
L - Hand of helix left
GRDPRIO Standard designation of the grade main application
HSS-Co
HAND Cutting direction
R - Right
ID Identifying order number
3109101051
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0035
LOC-03 DCONMS Diameter
3.5 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00352105
LS Shank length
50 mm
Materials
P,M,N,S,H
NOF Flute count
3
OAL Overall length
70 mm
OVERHANG LENGTH Overhang length
34 mm
PLCD Gate diameter
4.4 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
DIN374
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
2.5 mm
TCTR Thread tolerance class
ISO2X
TD Thread diameter
5 mm
THFT Thread form type
MF
THL Thread cutting part length
11 mm
THOD Thread designation
MF5x0.5-ISO2X
TP Thread pitch
0.5 mm
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.008 kg
