3104130013

3104130013

Yamawa
Артикул: 3104130013
В наличии
В корзину
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL02502105
DRVS Drive size
508 mm
FamilyProducts
GGST 5156 G1-11 C(2.5P) coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
ID Identifying order number
3104130013
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02502105
LS Shank length
2082.8 mm
Materials
K,N
NOF Flute count
4
OAL Overall length
4064 mm
OVERHANG LENGTH Overhang length
2189.48 mm
PLCD Gate diameter
768.274 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN5156
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
698.5 mm
TCTR Thread tolerance class
ISO228X
TD Thread diameter
844.525 mm
TDFR Thread diameter nominal fraction
1 in
THFT Thread form type
G
THL Thread cutting part length
736.6 mm
THOD Thread designation
G1-11-ISO228X
TPI Threads per inch
11 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BG - Tapping
WT Weight of item
0.65 kg
