Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 3102103074

3102103074

3102103074 3102103074

3102103074

Yamawa
Артикул: 3102103074
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL00602105
DRVS Drive size
4.9 mm
FamilyProducts
VUPO 374 2BX 5/16-24UNF coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
3102103074
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0060
LOC-03 DCONMS Diameter
6 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00602105
LS Shank length
46 mm
Materials
P,M,K,N,H
NOF Flute count
3
OAL Overall length
90 mm
OVERHANG LENGTH Overhang length
48.6 mm
PLCD Gate diameter
6.742 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
DIN374
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
5.291 mm
TCTR Thread tolerance class
2BX
TD Thread diameter
7.938 mm
TDFR Thread diameter nominal fraction
5/16 in
THFT Thread form type
UNF
THL Thread cutting part length
19 mm
THOD Thread designation
UNF5/16-24-2BX
TPI Threads per inch
24 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.02 kg
